60mm Wastegate
- Designed with a two-piece Billet dome made from 6061 aluminum, and a black anodized finish.
- The piston inside replaces the conventional diaphragm, which is a two-piece serviceable part. We pressure-tested and rated it for 150 psi working pressure.
-
On our piston we use a Hi-Temp O-ring. We use a nominal O-ring size, so if you have any mishaps replacements are easy.
- The wastegate valve is constructed from a super alloy mix to handle the hottest and harshest conditions your engine can throw at it. We also use this alloy mix to ensure fuels don't corrode the valve.
- All reference ports are 1/8 inch npt.
- Body is casted from stainless steel.
What's Included!
- Stainless inlet and outlet flanges
- Stainless clamps with hardware
- (3pcs) spring kit (approximate ratings for 5psi , 7psi and 14psi with a combined capability approximating 26psi depending on application)
- (2pcs) 1/8npt Stainless Barbs
- (2pcs) 1/8npt Stainless Plugs
INSTRUCTIONS
J
The 60mm gate is top of the line
S
Bad ass customer service
B
60mm Wastegate
S
So I upgraded the engine, the turbo, and the wastegate became a serious issue - not controlling at all - boost creep, tuning issues. This new 60mm gate is the tits! Once I put in the correct spring she’s rock steady at 10psi . Thanks for a great product.
C
Looks like a great quality piece and Fast shipping. I haven’t had a chance to install it yet but can’t wait to see how well it works. Thanks
